Electronic Dosing Pumps
We are specialized in designing tough and high performing range of Electronic Dosing Pumps (ANT), which are extensively used for chemical dosing in applications like water and waste water treatment.
Technical Specifications
Features :
- Electronically driven and mechanically actuated diaphragm
- Adjustable injection frequency (0 to 100 SPM)
- Compact size, light weight, more robust structure
- Unique double ball check NRVs for better dosing accuracy
- Solenoid drive with minimum moving parts
- Digital display of SPM (AM series)
- Electrical supply conditions in a specific country can be adjusted.
Series :
ED Series
Flow control by manual frequency variation
Features :
- Adjustable injection frequency (0 to 100 spm)
DD Series
Flow control by manual frequency and/or stroke length variation
Features :
- Adjustable injection frequency (0 to 100 spm) & stroke length
AM Series
Flow control by automatic flow variation, on receiving 4-20 mA signal.
Features :
- Digital display of spm
- Manually & automatic flow variation
- Enable to receive 4 - 20 mA signal
List of Accessories :
- Suction & Discharge Tubing of LDPE Material
- Strainer Cum Foot Valve
- Anti Syphon Valve in PP
- Built in electrical cable moulded with plug
- Pressure Relief Valve
- Calibration Pot
- Pulsation Dampener
- Local Control Panel
- Level Gauge
Optional Supply :
- Level Control Switch
- pH Meter
- Tank
